Blue Sea Systems 2312 BUSBAR 150 AMP 20X8-32 W/COVR
Product details
| Management number | 215151295 | Release Date | 2026/04/12 | List Price | $12.56 | Model Number | 215151295 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
150A Common BusBar with 20 screws and a cover (part number 2312). Max voltage: 300V AC/ 48V DC, Continuous Rating: 130A AC/ 150A DC. Terminal Screws: 20 x #8-32, Terminal Studs: 2 x 1/4"-20. Reinforced polycarbonate base with tin plated pure electrical copper for maximum conductivity and corrision resistance. 2 mounting holes accept #10 (M5) screws.
- 150A Common BusBar with 20 screws and a cover (part number 2312)
- Max voltage: 300V AC/ 48V DC, Continuous Rating: 130A AC/ 150A DC
- Terminal Screws: 20 x #8-32, Terminal Studs: 2 x 1/4"-20
- Reinforced polycarbonate base with tin plated pure electrical copper for maximum conductivity and corrision resistance
- 2 mounting holes accept #10 (M5) screws
| UPC | 632085023126 090090025670 973792080270 015568995637 012302038070 696582454616 190283665888 611104331633 |
|---|---|
| Color | Multicolor |
| Gauge | 1/4"-20 |
| Model | 2312 |
| Voltage | 300 Volts |
| Brand Name | Blue Sea Systems |
| Unit Count | 1.0 Count |
| Item Weight | 0.5 Pounds |
| Part Number | 2312 |
| Manufacturer | Blue Sea Systems |
| Material Type | Tin-Plated Copper, Glass Reinforced Polycarbonate |
| Mounting Type | Wall Mount |
| Connector Type | Screw |
| Current Rating | 150 Amps |
| Item Type Name | boating-electrical-equipment |
| Number Of Poles | 2 |
| Specification Met | UL |
| Number Of Contacts | 20 |
| Included Components | BusBar, Cover |
| Number of Positions | 20 |
| Warranty Description | Lifetime |
| Item Dimensions W x H | 9.5"W x 1.25"H |
| Global Trade Identification Number | 00632085023126 |
