Brixwell 135 Degrees Glass-to-Glass Mount Shower Door Hinge, Polished Chrome with Brass Accents, Solid Forged Brass, Beveled Edge, Fits 3/8" and 1/2" Glass, 3-9/16" Height, 2-9/16" Faceplate Width

The Brixwell Adjustable Glass To Glass Mount Shower Door Hinge 135 Degrees is designed for connecting glass panels in frameless shower enclosures where precise adjustment and smooth movement are required. Made from solid forged brass with a polished chrome with brass accents finish, this hinge provides a balanced combination of strength and appearance for bathroom fittings. It supports 3/8" and 1/2" thick glass and features a beveled edge profile that blends with other glass hardware and shower door components. This adjustable hinge allows fine-tuning with an in-out return adjustment range of up to 30 degrees, providing flexibility for installation and door alignment. It measures 3-9/16" in height, 2-9/16" in faceplate width, 2-3/16" in backplate width, and 3/16" in plate thickness, making it compatible with most glass-to-glass mount applications. The dual precision-wound stainless steel springs enable self-closing from 25 degrees and a 0-degree return, maintaining door stability during operation. Designed with a mouse-ear shape, the hinge allows proper fitment and adjustment after installation. It supports 80 lbs with two hinges and 120 lbs with three hinges, suitable for doors up to 36" wide. The hinge includes matching finish stainless steel hex clamping screws and a wrench for secure mounting.

• FINISH AND MATERIAL: Constructed from solid forged brass and finished in Polished Chrome with Brass Accents, this hinge blends functionality with a refined look, making it a reliable choice for glass-to-glass shower door installations.
• DIMENSIONS: Measures 3-9/16" height, 2-9/16" faceplate width, 2-3/16" backplate width, and 3/16" plate thickness. These precise dimensions allow a proper fit for glass-to-glass shower hinge configurations and frameless enclosures.
• GLASS COMPATIBILITY: Designed to fit glass panels with a thickness of 3/8" and 1/2" (10 and 12mm), this hinge ensures a secure connection and proper alignment for commonly used shower door sizes in bathrooms.
• LOAD CAPACITY: Each hinge supports up to 40 lbs, making it suitable for medium-weight glass panels. When using two hinges, the capacity increases to 80 lbs, and with three hinges, it supports up to 120 lbs, fitting shower doors up to 36" width.
• ADJUSTABLE FUNCTION: Offers 0-degree return adjustment up to 30 degrees in and out, providing flexibility during setup. This feature supports precise shower door alignment and consistent hinge movement in frameless glass installations.
• INCLUDED COMPONENTS: Package comes with pre-installed stainless steel Hex screws, additional Cross headscrews, and an Hex wrench. These included parts provide installers with the essential hardware and tool needed for quick installation.
