Screw Terminal Block Power Distribution Module (2x32 Position, DIN Rail Mount)
Product details
| Management number | 215610133 | Release Date | 2026/04/12 | List Price | $13.20 | Model Number | 215610133 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
1, Maximum Voltage: 250Vac/dc, Maximum Current Rating 40A(per channel). 2, Input terminals(A, B): pitch - 7.62mm/0.3", current 30A for per position(total 40A for A or B channel), wire size 26~10 AWG / 4.0mm square, stripping length 8mm, Metric M3 slotted screw. 3, Output terminals(A1~A32, B1~B32): pitch - 5.08mm/0.2", current 16A for per position(total 40A for A or B channel), wire size 28~12 AWG / 2.5mm square, stripping length 7mm, Metric M2.5 slotted screw. 4, FR-4 fiber glass PCB, dual copper layers. 5, High quality Taiwan fireproof nylon material DIN rail mount carrier (not China low quality carrier), can support width 35mm rail.
- Maximum Voltage: 250Vac/dc, Maximum Current Rating 40A(per channel).
- Input terminals(A, B): pitch - 7.62mm/0.3", current 30A for per position(total 40A for A or B channel), wire size 26~10 AWG / 4.0mm square, stripping length 8mm, Metric M3 slotted screw.
- Output terminals(A1~A32, B1~B32): pitch - 5.08mm/0.2", current 16A for per position(total 40A for A or B channel), wire size 28~12 AWG / 2.5mm square, stripping length 7mm, Metric M2.5 slotted screw.
- FR-4 fiber glass PCB, dual copper layers.
- High quality Taiwan fireproof nylon material DIN rail mount carrier (not China low quality carrier), can support width 35mm rail.
| Color | Green |
|---|---|
| Gauge | 12.0 |
| Model | MD-D1348 to D1351 |
| Pitch | 7.62 Millimeters |
| Voltage | 250 Volts |
| Brand Name | OONO |
| Part Number | MD-D1348 to D1351 |
| Manufacturer | CZH-LABS |
| Material Type | Copper |
| Mounting Type | DIN Rail Mount |
| Connector Type | Screw |
| Current Rating | 40 Amps |
| Number Of Poles | 32 |
| Number Of Contacts | 32 |
| Number of Positions | 32 |
