Vacuum Tube Rectifier 6V6GT Replaces 6V6 CV511 6P6P HiFi Audio Valve Electronic Amplifier Kit DIY Factory(1pcs)

vacuum tube6V6GT: power collector tube. Coated oxide side heating cathode.UH: 6.3VIH: 0.45AInterpolar capacitance:Gate to screen: G1-P 0.7pFInput: G1- (H+K+G2+G3) 9.0pFOutput: P - (H+K+G2+G3) 7.5pF T-9Maximum rated valueScreen voltage: 350VCurtain grid voltage: 315VScreen dissipation power: 14WDissipated power of curtain grille: 2.2WVoltage between hot wire and cathode: ± 200VGate circuit resistance: 0.1M (fixed bias) 0.5M (self feeding bias)Typical working characteristicsA1 class amplificationScreen voltage: 315V 180V 250VCurtain grid voltage: 315V 180V 250VGate voltage: -8.5V-12.5V-13VPeak input voltage: 8.5V 12.5V 13VZero signal screen current: 29mA 45mA 39mAMaximum signal screen current: 30mA 47mA 35mAZero signal curtain current: 3mA 4.5mA 2.2mAMaximum signal grid current: 4.0mA 7.0mA 6.0mAPlate internal resistance (approximate): 50000 50000 80000 Mutual conductivity: 3700 A/V 4100 A/V 3750 A/VLoad impedance: 5500 5000 8500 Total harmonic distortion: 8% 8% 12%Maximum signal output power: 2.0W 4.5W 5.5WAB; Class push-pull amplification (two tube values)Screen voltage: 250V 285VCurtain grid voltage: 250V 285VGate voltage: -1.5V -19VPeak input voltage (G-G): 30V 38VZero signal screen current: 70mA 70mAMaximum signal screen current: 79mA 92mAZero signal curtain current: 5.0mA 4.0mAMaximum signal grid current: 13.0mA 13.5mALoad impedance (P-P): 10000 80000 Total harmonic distortion: 5% 3.5%Maximum signal output power: 10W 14WThree pole connection methodScreen voltage: 250VGate voltage: -12.5VAmplification factor: 9.8Internal resistance of the plate: 1960 Mutual conductivity: 5000 A/VScreen current: 49.5mAGate voltage: (Ip=0.5mA) -36V==========Channels : 2 (2.0)Model Number : 6V6GTMaximum Power Per Channel : NO POWER

• vacuum tube
• The has good linearity low noise and good reliability
• The tube is designed for service as power rectifiers in AC operated receivers which require high currents.
• The service life longer and the failure rate greatly reduced.
• The special with signal and has low noises output.
• Durable and with a long life.
