YWBL-WH MXS12 Pneumatic Air Cylinder, Rail Cylinder High Precision Screwed Piston Rod Action 12×2mm Bore Size (MXS12-50), Cylinder
Product details
| Management number | 211682513 | Release Date | 2026/04/04 | List Price | $30.84 | Model Number | 211682513 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Specification:Item Type: Pneumatic Air CylinderMaterial: SteelColor: As picture shownModel: MXS12Optional Type: MXS12-10, MXS12-20, MXS12-30, MXS12-40, MXS12-50, MXS12-75, MXS12-100Optional Stroke: 10mm/0.4in, 20mm/0.8in, 30mm/1.2in, 40mm/1.6in, 50mm/2in, 75mm/3in, 100mm/3.9inBore: Approx. 12 × 2mm/0.5 x 0.1inUse Fluid: AirAction Mode: Double ActingMaximum Working Pressure: 0.7MPaMinimum Working Pressure: 0.15MPaEnvironment and Fluid Temperature: -10-+60 (Not Freeze)Piston Speed: 50-500mm/sCushion: Rubber Cushion (standard)Oiling: No NeedTakeover Caliber: M5×0.8Package List:1 x Pneumatic Air Cylinder
- Optional with adjustable stroke device (05mm), meet your differend needs.
- Doublecylinder designed, 2 times of output power, thin volume.
- The combination of the cylinder and the working table reduces the size of the whole rest.
- Can be installed from three sides, builtin magnetic rings, can be installed magnetic switch.
- Adopted crossed liquid column designed, small friction force, and there is no gaps between the cylinder and the work table, suitable for precision assembly.
| Size | MXS12-50 |
|---|---|
| Finish | Finish |
| Material | Material |
| Item Weight | 12.6 ounces |
| Part Number | YWBL-WH5adb8xrhp2-15 |
| Manufacturer | YWBL-WH |
| Power Source | PowerSource |
| Spout Height | 1 Centimeters |
| Included Components | inc |
| Installation Method | InstallationMethod |
| Item Package Quantity | 1 |
